Ducati SPORTCLASSIC PAUL SMART 1000 LIMITED EDITION 2006 User Manual

E
25
Setting the gear change and rear brake pedals
The gear change and rear brake pedals can be adjusted to
suit the preferred riding position of each rider.
To set the gear change pedal, hold the rod (1) and loosen
lock nuts (2) and (3).
Note
Nut (2) has a left-hand thread.
Fit an open-end wrench to hexagonal element of linkage
(1) and rotate until setting pedal in the desired position.
Tighten both check nuts onto linkage.
1 32
fig. 17
