Ducati SUPERSPORT User Manual

Error warnings
The instrument panel manages error warnings in
order to allow the rider to identify any abnormal
motorcycle behaviour in real time.
Upon Key-On, in case of errors, the instrument panel
turns on the MIL light (A) (in case of errors directly
connected to the engine control unit) or the Generic
Error light (B) (in case of any other errors).
During normal operation, when an error is triggered,
the instrument panel turns on the MIL light (A) or the
Generic Error light (B).
Warning
When one or more errors are displayed, always
contact a Ducati Dealer or authorised Service Centre.
A
B
Fig. 62
102

Ducati SUPERSPORT Specifications

General

Displacement	937 cc
Transmission	6-speed
Frame	Tubular steel Trellis frame
Seat Height	810 mm (31.9 in)
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Max Power	110 hp @ 9, 000 rpm
Max Torque	93 Nm (68.7 lb-ft) @ 6, 500 rpm
Front Suspension	43 mm upside-down fork
Rear Suspension	Sachs monoshock, adjustable for preload and rebound damping
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Dry Weight	184 kg (405.7 lb)
Fuel Tank Capacity	16 l (4.2 US gal)
