Ducati SUPERSPORT User Manual

Clutch lever
Lever (1) disengages the clutch. When the clutch
lever (1) is operated, drive from the engine to the
gearbox and the drive wheel is disengaged. Using the
clutch properly is essential to smooth riding,
especially when moving OFF.
Important
Using the clutch properly will avoid damage to
transmission parts and spare the engine.
Note
The engine can be started with the side stand
down and the gearbox in neutral. If starting with a
gear engaged, pull in the clutch lever (in this case the
side stand must be up).
1
Fig. 123
202

Ducati SUPERSPORT Specifications

General

Displacement	937 cc
Transmission	6-speed
Frame	Tubular steel Trellis frame
Seat Height	810 mm (31.9 in)
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Max Power	110 hp @ 9, 000 rpm
Max Torque	93 Nm (68.7 lb-ft) @ 6, 500 rpm
Front Suspension	43 mm upside-down fork
Rear Suspension	Sachs monoshock, adjustable for preload and rebound damping
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Dry Weight	184 kg (405.7 lb)
Fuel Tank Capacity	16 l (4.2 US gal)
