Ducati SUPERSPORT User Manual

Electric system
Basic electric items are:
Headlight:
No. 1 bulb H1 12V 55W (low beam);
No. 1 bulb H7 12V 55W (high beam).
LED parking light (with DRL) type:
No. 14 LEDs 12V – 0.8W.
Tail light:
No. 8 LEDs 13.5V – 0.45W (parking light).
No. 12 LEDs 13.5V – 2.8W (stop light).
Number plate light:
No. 3 LEDs 13.5V - 0.67W.
Electric controls on handlebars.
Front turn indicators:
No. 1 LED 13.5V - 3.1W
Rear turn indicators:
No. 1 bulb R10W 12V-10W.
Horn.
Stop light switches.
Number plate light: LED type.
Battery 12 V - 10 Ah.
System voltage 12 V.
GENERATOR 490W to 14V.
Electronic rectifier, protected by a 30A fuse located
on the solenoid starter, under the battery
(C, Fig. 199).
Starter motor: 12V-0.7 kW.
Note
For bulb replacement instructions, please see
the paragraph "Replacing the high and low beam
bulbs".
302

Ducati SUPERSPORT Specifications

General

Displacement	937 cc
Transmission	6-speed
Frame	Tubular steel Trellis frame
Seat Height	810 mm (31.9 in)
Engine Type	L-twin, 4 valves per cylinder, Desmodromic, liquid cooled
Max Power	110 hp @ 9, 000 rpm
Max Torque	93 Nm (68.7 lb-ft) @ 6, 500 rpm
Front Suspension	43 mm upside-down fork
Rear Suspension	Sachs monoshock, adjustable for preload and rebound damping
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Dry Weight	184 kg (405.7 lb)
Fuel Tank Capacity	16 l (4.2 US gal)
