SECTION I
GENERAL INFORMATION
1.1. INTRODUCTION
1.1.1. GENERAL. This manual contains the description, operation and
maintenance of the TS200 Ultrasonic Test Set manufactured by Dukane Cor-
poration, Seacom Division, 2900 Dukane Drive, St. Charles, Illinois 60174.
See Figure 1.
1.1.2. SYMBOLS AND ABBREVIATIONS. All symbols and abbrevia-
tions used in this manual are in accordance with the ANSI Y14.15 and
MIL-STD-12, respectively.
1.2. GENERAL DESCRIPTION
1.2.1 FUNCTION. The TS200 is a battery operated heterodyne type
receiver that operates at an ultrasonic frequency of 37.5 kHz. The test set
was designed primarily as a self-contained, hand-held functional tester for
testing underwater acoustic beacons. Utilizing the internal microphone and
loudspeaker, the Test Set can perform an operational test on Dukane Corpo-
ration DK Series beacons without removing the beacon from its mount on
the aircraft. The test set can also be used to perform a voltage measure-
ment to test the battery in a Dukane underwater beacon.
1.2.2. SPECIFICATIONS. The specifications for the TS200 are given in
Table 1.
03-TM-0045 REV 00
