SECTION II
OPERATION
2.1. OPERATION
A. Turn the test set ON using the small slide switch located on the left side
of the housing.
B. If the display reads LB the TS200 battery voltage has fallen below the
level required for operation of the test set and the 9-Volt battery should
be replaced. See Maintenance Section 3.2
C. Testing Beacon Voltage. Attach the test probe clip to the pinger case.
See Figure 2. The clip has a spring action that will allow it to slip over
the housing on the beacon. Place the tip of the probe in contact with the
silver pad on the white dome at the end of the beacon. The display will
show the battery voltage of the beacon. Refer to the appropriate beacon
manual for the acceptable range of the beacon battery voltage.
D. Operational Test. Place the probes on the beacon as described above
and press the red button on the TS200 (the test set display will be blank
during this operation). The beacon should activate and a pinging sound
will be audible from the TS200. Please note that high levels of back-
ground noise can interfere with this test. If difficulty is experienced in
hearing the beacon the operator should repeat the test in a quieter area.
03-TM-0045 REV 00
