43
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Wiring & Lighting Kit
LH Side
RH Side
1 898
3
4
12 11
13 10
13
14
15
15
14
10
11 12
6 6
3
4
2
7
7
10
15
1616 16 10 1615
ITEM PART No. DESCRIPTION QTY
1 22346 LH Lamp Bracket Assembly 1
2 22347 RH Lamp Bracket Assembly 1
3 43435 Combination Rear Lamp 2
4 43436 Marker Lamp 2
5 43437 Trailer Round Connector Plug 1
6 43438 5 Core Trailer Flex (15 to 21 Run x 12m, 23/25 Run x 13m) 1
7 43443 White 1mm Appliance Wire x 1m 1
8 43444 Brown 1mm Appliance Wire x 1m 1
9 43448 No. 6 Rubber Grommet 1
10 45122 M6 Class 8.8 Zinc Plated Hex Nut 1
11 45137 M8 Nylock Nut 4
12 44962 M8 x 30 Class 8.8 Zinc Plated Bolt 4
13 44951s M6 x 16 Class 8.8 Zinc Plated Set Screw 4
14 45860 No. 12 x 3/4” Pan PZ Zinc Plated Self Tapping Screw 4
15 - 5W Festoon Bulb 15 x 44mm 4
16 - 21W Festoon Bulb 15 x 44mm 4
To Next Page
