45
Pt. No. 67304
Issue 1217
‘Enviro’ Seed Drill Front Disc Assembly
5
58
8
10
7
7 9
4
3
4
3
6
ITEM PART No. DESCRIPTION QTY
1 22000 406 x 4 Plain Disc 6 Hole 1
2 22001 406 x 4 Fluted Disc 6 Hole 1
3 11351 Bearing 6305-2RS1 2
4 17537 6 Hole Single Bearing Housing 2
5 22078 Seal Collar 2
6 22102 Bearing Spacer 1
7 22080 25mm Bore Dust Cap 2
8 43352 Vee Ring Seal V-40A 2
9 45002s M10 x 25 Class 8.8 Zinc Plated Set Screw 6
10 45138 M10 Nylock Nut 6
11 22003 Action 2000 Fluted Disc 406 x 4 (6 Hole) 1
11
Note: Item 8 Vee Ring Seal
Orientation
