Pt. No. 67394

Issue 1121

‘Enviro DD30’ Complete Assembly

ITEM PART No. DESCRIPTION QTY

1 Refer Page 42-45 Main Frame & Drawbar Assembly -

2 Refer Page 46 Wheel Leg 2

3 Refer Page 50-57 Disc Assemblies -

4 Refer Page 58-63 Seed Metering Drive Pedestal 1

5 Refer Page 64-65 Box Mounting Frame 1

6 Refer Page 66-67 Footboard & Ladder 1

7 Refer Page 68-71 Seed Box & Metering Units 1

8 Refer Page 72-73 Fan & Air Hoses 1

9 Refer Page 75 Farmscan Jackal 1

10 Refer Page 76-77 Lighting Kit (Optional) -

11 Refer Page 78-79 Rear Tow Hitch & Tine Harrow Mount (Optional) -

12 Refer Page 80-81 Tine Harrow (Optional) -

13 Refer Page 82-83 Uni-Roller (Optional) -

14 Refer page 84-87 Weights (Optional) -

Duncan Enviro DD30 - Page 43
