49
Pt. No. 67439
Issue 1120
‘Enviro DD35’ Wheel Hydraulics
ITEM PART No. DESCRIPTION QTY
1 26702 3.5” x 6.5” Master Rephasing Cylinder (Includes pin) 1
2 26703 3.25” x 6.5” Slave Rephasing Cylinder (Includes pin) 1
3 43848 Stroke Limiting Collar 7/8” (where fitted) 1
4 60866 Hydraulic Hose, 2.70m 1
5 60864 Hydraulic Hose, 2.70m 1
6 60864 Hydraulic Hose, 2.70m 1
7 60863 Hydraulic Hose, 5.45m 1
8 43028 3/8” Flow Control 1
9 43391 3/8” Dowty Washer 3
10 43392 3/8” BSPP Male Nipple 2
11 43393 3/8” BSP S/S Ball Valve 1
12 60856 Hydraulic Valve Support Assy 1
13 43147 1/2” BSP Quick Release Coupling 2
14 43617 Dust Cover 2
15 43280 3/4” UNO to 3/8” BSP Nipple 4
16 45033 M12 x 120 Bolt 1
17 45139 M12 Nyloc Nut 1
18 44957 M6 X 50 Bolt 2
19 45136 M6 Nyloc Nut 2
20 22270 Clevis Spacer 2
21 22262 Clevis Pin Assembly 2
22 45418s M10 x 25 Set Screw 2
23 45166 M10 Spring Washer 2
24 26558 Clevis Pin 2
25 45272 R Clip 2
