51
Pt. No. 67439
Issue 1120
‘Enviro DD35’ Disc Assemblies
ITEM PART No. DESCRIPTION QTY
1 60811k Straight Coulter with Press Wheel (LH Leading) 6
2 66394k Straight Coulter with Press Wheel (RH Leading) 7
3 66393k Straight Coulter no Press Wheel (RH Leading) 2
4 60812k 40 R Offset Coulter with Press Wheel (LH Leading) 2
5 66395k 40 R Offset Coulter with Press Wheel (RH Leading) 2
6 60813k 40 L Offset Coulter with Press Wheel (LH Leading) 3
7 66396k 40 L Offset Coulter with Press Wheel (RH Leading) 1
8 60814k 75 L Offset Coulter with Press Wheel (LH Leading) 1
9 60815k 75 R Offset Coulter with Press Wheel (LH Leading) 1
10 60807k 90 R Offset Coulter with Press Wheel (RH Leading) 1
11 60808k 90 L Offset Coulter with Press Wheel (LH Leading) 1
Individual parts and sub assemblies are shown in the next few pages…
Travel direction
Left Hand Side
Right Hand Side
Offset is 75 L Disc is LH Leading
Disc Identification example
To Next Page
