55
Pt. No. 67439
Issue 1120
‘Enviro DD35’ Disc Assemblies
ITEM PART No. DESCRIPTION QTY
1 66403 Press Wheel Fixed Plate RH 1
2 43953 Nylon Washer 30 x 70 x 2 2
3 66402 Press Wheel Fixed Plate LH 1
4 45140 M16 Nyloc Nut 3
5 45020 M12 x 35 Grade 8.8 Z/P Bolt 1
6 45023 M12 x 50 Grade 8.8 Z/P Bolt 1
7 Refer Page 56 Disc Mount Sub Assy (Straight shown) 1
8 63149 Disc Scraper Assembly (contains items 9 to 16 below):- 1
9 44954s M6 x 25 Grade 8.8 Z/P S/Screw 3
10 63144 Scraper Mounting Strap 1
11 63145C Scraper Casting LH DDE 1
12 45136 M6 Nyloc Nut 3
13 63147 Scraper Tensioner 1
14 63146C Scraper Casting RH DDE 1
15 63143 Scraper Hinge 2
16 45122 M6 Grade 8.8 Hex Nut Z/P 3
17 45152 M10 Light Flat Washer 3
18 45166 M10 Spring Washer Z/P 3
19 45001s M10 x 20 Grade 8.8 Z/P S/Screw 3
20 63084 Press Wheel Bearing Sleeve 1
21 43939 Bearing 6205 2
22 66407 Press Wheel Arm Welded Assy 1
23 45052 M16 x 140 Grade 8.8 Z/P Bolt 1
24 29267 15”x80mm Wedge P/Wheel Scraper 1
25 45235 M12 x 35 CSK Socket HD Screw 1
26 45139 M12 Nyloc Nut 1
27 45045 M16 x 75 Grade 8.8 Z/P Bolt 2
28 10283 Oil Seal 2
29 61022 Bearing Mount for 6305 2
30 11351 Bearing 6305 2
31 43573 Press Wheel 15”x80 Solid Wedge 1
32 61021 Bearing Spacer for 6305 1
33 60294 Spring 1
34 - HD Flat Washer 1
35 66409 Slide Bar W/Assy 1
To Next Page
