Pt. No. 67439
Issue 1120
‘Enviro DD35’ Jockey Drive
ITEM PART No. DESCRIPTION QTY
1 63128 21T Sprocket 1/2”P 20mm Bore 2
2 74262 Box Drive Shaft Long DD35 2
3 22294 Sprocket Key (6 x 6 x 25) 6
4 45137 M8 Nyloc Nut 21
5 45151 M8 Light Flat Washer Z/P 21
6 44992s M8 x 20 Grade 8.8 Z/P S/Screw … 21
7 43387 Bearing Housing PF47 (1 housing = 2 flanges) 6
8 43385 Bearing YET204 20mm 6
9 45181 M8 x 12 Socket/HD Grub Screw (knurled point) 4
10 25744 Jockey Wheel and Axle W/Assy 1
11 25724 13T Sprocket 1/2”x 20mm Bore 1
12 45180 M8 x 10 Socket/HD Grub Screw (knurled point) 6
13 47625 M16 Bellville Washer S/S304 1
14 17127 Bearing 6204 2
15 25739 Jockey Axle Inner Spacer 1
16 25735 Jockey Wheel Arm W/Assembly 1
17 25727 Jockey Axle Outer Spacer 1
18 45140 M16 Nyloc Nut 1
19 25746 Jockey Drive Swing Guard 1
20 45156 M6 H/D Flat Washer Z/P 2
21 45164 M6 Spring Washer 2
22 44951s M6 x 16 Grade 8.8 Z/P S/Screw 2
23 45119 M16 Grade 8.8 Hex Half-Nut Z/P 1
24 23376 Chain Tensioner Anchor 30 Ext 1
25 22523 Torsion Spring Right Hand 1
26 22535 Chain Tension Roller 1
27 23373 Chain Tensioner Short L/H Assy 1
28 45043 M16 x 65 Grade 8.8 Z/P Bolt 1
29 25725 Jockey Arm Pivot Spacer 2
30 43939 Bearing 6205 2
31 25729 Jockey Arm Pivot Outer Spacer 1
32 45163 M24 H/D Flat Washer Z/P 1
33 25742 38T Sprocket 1/2” x 25mm Bore 1
34 43386 Bearing YET205 25mm 3
35 44033 Jackal Clamp & Magnet AA-117 1
36 30359 Bearing Housing PF52 (1 housing = 2 flanges) 3
37 22050 Crank Adapter Assembly 1
38 63127 15T Double Sprocket 1/2”P 25mm 1
39 63126 Drive Pedestal Main Shaft 1
40 72913 Sensor Mounting bracket 1
41 44035 Proximity Sensor - Blue AA2010P 1
42 45002s M10 x 25 Grade 8.8 Z/P S/Screw 1
43 45152 M10 Light Flat Washer Z/P 1
44 45138 M10 Nyloc Nut 1
45 45186 M10 x 12 SKT HD Grubscrew (knurled point) 2
