67
Pt. No. 67439
Issue 1120
‘Enviro DD35’ Seedbox Frame
ITEM PART No. DESCRIPTION QTY
1 63183 Hopper Mount Frame W/Assy 1
2 74249 Side Support W/Assy DD35 2
3 74252 LH Frame Brace Front DD35 W/As 1
4 74256 RH Frame Brace Front DD35 W/As 1
5 63211 Foot Stand W/Assy 2
6 45039 M16 x 45 Grade 8.8 Z/P Bolt 8
7 45140 M16 Nyloc Nut 24
8 45040s M16 x 50 Grade 8.8 Z/P S/Screw 12
9 45043s M16 x 65 Grade 8.8 Z/P S/Screw 4
10 45033 M12 x 120 Grade 8.8 Z/P Bolt 8
11 63189 Frame Footplate 2
12 45139 M12 Nyloc Nut 8
To Next Page
