71
Pt. No. 67439
Issue 1120
‘Enviro DD35’ Seed/Fert Box
ITEM PART No. DESCRIPTION QTY
1 44110 Distributor Head 32R 2
2 63179 Blanking Plug Seed Distr Head (5 per head) 10
3 63150 MS Hopper W/Assy 1
4 63177 14 Hole Tube Inset Panel W/Assy (1 per compartment) 2
5 44951sss M6 x 16 316 S/S S/Screw 48
6 45136 M6 Nyloc Nut 60
7 43373 Edgetrim Black (per metre) -
8 63167 Mesh Grid Filter Hopper Bottom 1
9 Refer Page 72 Metering Unit 2
10 63204 13 Hole Tube Inset Panel W/Assy (1 per compartment) 2
11 63260P Hopper Gasket Support Profile 2
12 45909ss M6 x 20 Pan Pozi S/S M/C Screw 12
13 63166P Outlet H/Moon Flange Profile 4
14 63173 Cover Holding Extrusion 1
15 45150 M6 Light Flat Washer 12
16 63182 Hopper Cover Support Rod 2
17 43430 Plastic lashing Hooks (not shown) 11
18 63174 Ripstop Hopper Cover (not shown) 1
19 63251 Air Delivery Hose Long (not shown) 1
20 63252 Air Delivery Hose Short (not shown) 1
21 44167 32mm/m Oil Helixflex Smooth Hose 47mtr
22 43691 38mm Nylaflow Air Seeder Hose 83mtr
To Next Page
