81
Pt. No. 67439
Issue 1120
ITEM PART No. DESCRIPTION QTY
1 63035 Rear Towhitch Welded Assembly 1
2 63297 Tine Harrow Stub Assembly 2
3 45040 M16 x 50 Grade 8.8 Z/P Bolt 8
4 45043 M16 x 65 Grade 8.8 Z/P Bolt 4
5 45045 M16 x 75 Grade 8.8 Z/P Bolt 4
6 45140 M16 Nyloc Nut 16
Note: Item 2 ( 1 per side) is required if a Tine Harrow is to be fitted.
‘Enviro DD35’ Rear Tow Hitch (Optional)
To Next Page
