83
Pt. No. 67439
Issue 1120
‘Enviro DD35’ Tine Harrow (Optional)
ITEM PART No. DESCRIPTION QTY
1 RFT35 Tine Harrow 3.5m 1
2 60426 Tine Harrow Strut W/Assy 2
3 60428 Strut Bolt Plate 2
4 60430 Swinging Arm W/Assy 2
5 60435 Guidingbar W/assy 2
6 60437 Levelling Harrow Spring 2
7 60438 Guiding bar Bush 2
8 60439 Guiding Spacer 4
9 43118 Grease Nipple Straight 2
10 45006 M10 X 45 Gr 8.8 bolt Z/P 4
11 45138 M10 Nyloc Nut 36
12 45050 M16 X 120 Gr 8.8 bolt Z/P 8
13 45140 M16 Nyloc Nut 8
14 45073 M20 X 130 Gr 8.8 bolt Z/P 6
15 45161 M20 HD flat washer Z/P 4
16 45141 M20 Nyloc Nut 6
17 60423 Levelling Harrow Bar W/Assy 2
18 60440 Swinging Bracket Spacer 4
19 60441 Levelling Harrow Pivot Pin W/Assy 2
20 43675 1/4” x 1 1/2” Lynch Pin 2
21 60255 Levelling Harrow Tine -LH 12
22 60256 Levelling Harrow Tine -RH 12
23 60422P# Double Retaining Plate Profile 24
24 45016 M10 X 100 Gr8.8 Bolt Z/P 24
25 43120 Grease Nipple 90° 2
26 60421 Tine Harrow Bracket 2
27 45013 M10 x 80 Gr 8.8 bolt Z/P 8
28 60420 Harrow Bar Clamp Plate 2
Note: The Rear Tow and Tine Harrow Mounting kit are required (see previous page)
