COMPONENTS AND CONTROLS
PIC. 1
1. Handle
2. Fuel cap
3. Fuel cap vent
4. Oil container
5. Spark plug socket
6. Screw driver
7. Screw driver handle
8. Spark plug access panel
9. AC socket 1
10. Earth point
11. Low oil level indicator (yellow)
12. Overload indicator (red)
13. Output indicator (green)
14. Economy switch
15. AC restart button
16. DC circuit breaker
17. 12V DC cigarette lighter socket
18. 5V USB socket
19. AC socket 2
20. Fuel tap valve and engine switch
21. Recoil starter handle
22. Access panel (Air filter & oil filler)
23. Extendable Handle
24. Wheels
PIC. 1
1
2
3
4
5
6
7
22
21
20
13 14 15
16
17
10
199
18
11
12
8
24
23
