BOURDON SYSTEM SELECTION
(1)
Ordering Bourdon Tube Socket Tube Range Selection NPT
Code & Tip Material
(1)
Material Type Limits (psi) Conn.
(3)
S 316 stainless steel 316 stainless steel C-Tube Vac/800
1
⁄
1
⁄
1
4
⁄4⁄
,
1
⁄
1
⁄
1
2
⁄2⁄
&
1
⁄
1
⁄
1
8
⁄8⁄
(2)
S 316 stainless steel 316 stainless steel Helical 1000/15,000
1
⁄
1
⁄
1
4
⁄4⁄
,
1
⁄
1
⁄
1
2
⁄2⁄
&
1
⁄
1
⁄
1
8
⁄8⁄
(2)
DUAL-SCALE AMMONIA RANGES
Compound in Hg/psi °F Outer Arc
Vac/150 –40/84°F
Vac/300 –40/125°F
(1) For selection of the correct Bourdon system material, see the media application table on page 243.
(2)
1
⁄
1
⁄
1
2
⁄2⁄
NPT available 100mm lower only.
(3)
1
⁄
1
⁄
1
4
⁄4⁄
" JIS, BSP or DIN threads available.
TO ORDER THIS 1008 PRESSURE GAUGE:
Select: 63 1008 S (L) 02L XXX 1000#
1
. Dial size–63mm or 100mm
2. Case type–1008
3. Tube and socket material
4. Liquid fi lled (glycerin), leave blank if dry
5. Connection size–
1
⁄
1
⁄
1
8
⁄8⁄
(01),
1
⁄
1
⁄
1
4
⁄4 ⁄
(02),
1
⁄
1
⁄
1
2
⁄2⁄
(04)
6. Connection location–Lower (L), Back (B)
7. Optional Features–see page 176
8. Standard pressure range–1000 psi
STANDARD RANGES
Single-Scale Dial Dual-Scale Dial
psi psi Inner Arc kPa Outer Arc
0/15 0/15
0/100
0/30 0/30 0/200
0/60 0/60 0/400
0/100 0/100 0/700
0/160 0/160 0/1100
0/200 0/200 0/1400
0/300 0/300 0/2000
0/400 0/400 0/2800
0/600 0/600 0/4000
Vacuum in.Hg in.Hg Vacuum
30/0 30/0 –100/0
Comp. in.Hg/psi in.Hg/psi kPa
30/15 30/15 –100/100
30/30 30/30 –100/200
30/60 30/60 –100/400
30/100 30/100 –100/700
30/150 30/150 –100/1000
30/300 30/300 –100/2000
psi psi Inner Arc kPa Outer Arc
0/1000 0/1000 0/7000
0/1500 0/1500 0/10,000
0/2000 0/2000 0/14,000
0/3000 0/3000 0/20,000
0/5000 0/5000 0/34,000
0/6000 0/6000 0/40,000
0/7500 0/7500 0/50,000
0/10,000 0/10,000 0/70,000
0/15,000 0/15,000 0/100,000
Stainless Steel-Case Gauge
Type 1008S, ASME B 40.1
Grade B (±3-2-3% of span)
DESIGNED FOR SAFETY AND
LONGER LIFE
• Patented PowerFlex™ movement
isolates movement from shock and
vibration for longer life
• All stainless, all-welded construc-
tion for long life
• New PLUS!
™
Performance Option:
™
Performance Option:
™
- Liquid-fi lled performance in a dry
gauge
- Fights vibration and pulsations
without liquid-fi ll headaches
- See pages 6-7 for details
- Order as option XLL
• True Zero™ pointer indication – no
stop pin to mask false zero reading
– ensures safety and process control
OTHER FEATURES:
Available in 63mm and 100mm dials
sizes, 1008S pressure gauges are fi eld
liquid fi llable and fi eld convertible for
panel mounting. ASME Grade B, 3-2-3%
accuracy is standard. The gauge is
available dry, liquid-fi lled weatherproof
or hermetically sealed and
now
with
now with now
PLUS!
™
performance option.
™
performance option.
™
Select: 63 1008 S (L) 02L XXX 1000#
