~35~
4.4.3 Manual Mode
After the “STARTUP” procedures, the DB-280 will automatically set itself MANUAL operation and
flashing "LOAD BOOK" display. Note that the “NOTCH” LED is ON.
1
(1) Press the “OPEN” button and place the book block inside
the clamps. Be sure to follow the label instructions on the
clamp to load the book block to the RIGHT of the red line,
then slide the book block to the far LEFT of the clamps and
you will see the flashing "PUSH CLOSE" display.
Step 1:
Load book to the
RIGHT of the red line.
Step 2:
Slide the book to
The far LEFT.
(2) Then press the “CLOSE” button to clamp down the book
block and you will see the flashing "PUSH START" display.
Note:
In case you need to adjust the book block after you have closed
the clamps, you can press the "OPEN" button twice to release it.
The LED display will show "PUSH CLOSE". After you have
adjusted the book block, you have to press "CLOSE" button until
the clamps close. Then you will see the flashing "PUSH START"
display again.
(3) Press the “START” button. The LED display of control
panel will show a “Å” sign and the clamp station will move
over the notching station for notching.
