~37~
4.4.4 Auto Mode
Note: All books done in this mode must be same thickness.
1
In the MANUAL mode, make one book.
Centering the cover to the centered point and adjust the side
guide.
2
Press “FUNCTION” button to switch to “AUTO” operation.
The “AUTO” LED will be lit and display flashing "LOAD
BOOK" as shown. Note: The “NOTCH” LED is ON.
Step 1:
Load book to the
RIGHT of the red line.
Step 2:
Slide the book to
The far LEFT.
3
(1) Press the “OPEN” button. Be sure to follow the label
instructions on the clamp to load the book block to the RIGHT
of the red line, then slide the book block to the far LEFT of the
clamps and you will see the flashing "PUSH CLOSE" display.
(2) Then press the “CLOSE” button to clamp down the book
block and you will see the flashing "PUSH START" display.
Note:
In case you need to adjust the book block after you have closed
the clamps, you can press the "OPEN" button twice to release it.
The LED display will show "PUSH CLOSE". After you have
adjusted the book block, you have to press "CLOSE" button
until the clamps close. Then you will see the flashing "PUSH
START" display again.
(3) Press the “START” button. The LED DISPLAY of control
panel will show the “Å” sign. The clamp station will move to
the left side of DB-280 and will remain there.
