FRONT COVER AND DRIVE ASSEMBLY
Item No. Part No. Description Qty.
1 CV3540P-DUPURE DuPure Impression Plus
®
cover 1
2 CV3107-1 Motor 1
3 CV3106-1 Drive bracket & spring clip 1
4 CV3579WI PC board, CC 1
5 CV3110 Drive gear, 12 x 36 3
6 CV3109 Drive gear cover 1
7 CV3002CC Drive assembly, CC -
CV3186 Transformer, 110V-12V 1
CV3543 Optional weather cover 1
NOTE: Battery Location
