17
INJECTOR ASSEMBLIES
Item No. Part No. Description Qty.
1 CV3176 Injector cap 1
2 CV3152 O-ring 135 1
3 CV3177-01 Injector screen 1
4 CV3010-1Z Injector assembly plug 1
5
CV3010-1A A injector assembly, BLACK
1
CV3010-1B B injector assembly, BROWN
CV3010-1C C injector assembly, VIOLET
CV3010-1D
D injector assembly, RED
CV3010-1E E injector assembly, WHITE
CV3010-1F F injector assembly, BLUE
CV3010-1G G injector assembly, YELLOW
CV3010-1H H injector assembly, GREEN
CV3010-1I I injector assembly, ORANGE
CV3010-1J J injector assembly, LIGHT BLUE
CV3010-1K K injector assembly, LIGHT GREEN
not shown CV3170 O-ring 011, lower *
not shown CV3171 O-ring 013, upper *
* The injector plug and the injector each use one lower and one upper o-ring
BRINE ELBOW ASSEMBLY
Item No. Part No. Description Qty.
1 CV3195-01 Refill port plug assembly 1
2 CH4615 Elbow locking clip 1
3 CS 1197 Tube insert, 3/8" 1
4 CJCPG-6PBLK Nut, 3/8" 1
5 CH4613 Elbow cap, 3/8" 1
6 CV3163 O-ring 019 1
REPLACEMENT PARTS:
