DuPure Impression Plus Series - Bypass Valve Parts

16
REPLACEMENT PARTS:
BYPASS VALVE
Item No. Part No. Description Qty.
1 CV3151 Nut, 1" quick connect 2
2 CV3150 Split ring 2
3 CV3105 O-ring 215 2
4 CV3145 Bypass rotor, 1" 2
5 CV3146 Bypass cap 2
6 CV3147 Bypass handle 2
7 CV3148 Bypass rotor seal retainer 2
8 CV3152 O-ring 135 2
9 CV3155 O-ring 112 2
10 CV3156 O-ring 214 2
