19
WATER METER & METER PLUG
Item No. Part No. Description Qty.
1 CV3151 Nut, 1" QC 1
2 CV3003 Meter assembly, includes items 3 & 4 1
3 CV3118-01 Turbine assembly 1
4 CV3105 O-ring 215 1
5 CV3003-01 Meter plug assembly 1
6 CV3013 Optional mixing valve 1
REPLACEMENT PARTS:
Although no tools are necessary to assemble
or disassemble the valve, the Service Wrench,
(shown in various positions on the valve) is
available to aid in assembly or disassembly.
SERVICE WRENCH - CV3193-01
