DuPure Impression Plus Series - Brine Tank Assembly; Safety Float Brine Elbow

20
REPLACEMENT PARTS:
BRINE TANK ASSEMBLY
Item No. Part No. Description Qty.
1
CG2195-14 15" x 17" DuPure brine tank cover 1
CG2189 Round brine tank cover, black 1
2
CG21517RB1CDL 15" x 17" platinum brine tank 1
CG21840CB1C00 18 " x 40" round brine tank, black 1
3
CH1030-27 4" x 27" brine well (18 x 33 BT) 1
CH1030-34.5 4" x 34.5" brine well (18 x 40, 24 x 40 BT’s) 1
4 CH1018 2 piece overflow set 1
5 CH4500-48 474 air check assembly, 1/2" x 48" 1
6 CH4640-32 474 float assembly, 32" w/ 2 grommets 1
7 CH4600-50 474 safety brine valve w/ .5 gpm glow control 1
8 CH7016 Cap 4" brine well 1
9 CH4626 Nut safety brine valve stand off 1
ASSEMBLIES
10
CH4700-27WR-1 .5 gpm safety float assembly, 18" x 33"
CH4700-34.5WR-1 .5 gpm safety float assembly, 18" x 40"
SAFETY FLOAT BRINE ELBOW
Item No. Part No. Description Qty.
1 CH4655 474 .5 gpm flow control 1
2 CV3163 O-Ring 019 1
3
CH4613 3/8" elbow cap 1
CH4612 1/2" elbow cap 1
4 CH4615 Elbow locking clip 1
5
CJCPG-5PBLK 3/8" compression nut 1
CJCPG-8PBLK 1/2" compression nut 1
6 FP10332 Poly tube insert 1
1
2
3
4
5
6
2
3
4
5
6
7
9
1
8
10
