1-8-2 HM212FIS
TV screen
Note:
OSD for mechanical error will be displayed for 5 sec. after the mechanical error occurs.
When reel or capstan mechanism is not functioning
correctly
When tape loading mechanism is not functioning cor-
rectly
When cassette loading mechanism is not functioning
correctly
When the drum is not working properly
P-ON Power safety detection
Cause Indicator Active
When reel or capstan mechanism is not
functioning correctly
“A R” is displayed on a TV screen. (Refer to Fig. 1.)
When tape loading mechanism is not
functioning correctly
“A T” is displayed on a TV screen. (Refer to Fig. 2.)
When cassette loading mechanism is not
functioning correctly
“A C” is displayed on a TV screen. (Refer to Fig. 3.)
When the drum is not working properly
“A D” is displayed on a TV screen. (Refer to Fig. 4.)
P-ON Power safety detection
“A P” is displayed on a TV screen. (Refer to Fig. 5.)
A
R
Fig. 1
A
T
Fig. 2
A
C
Fig. 3
Fig. 4
A
D
A
P
Fig. 5
