20061226 1-17-1 HM212EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
MCV CBA
Consists of the following:
1VSA14699
MAIN CBA (MCV-A)
JACK CBA (MCV-C)
SENSOR CBA
----------
----------
0VSA14893
Ref. No. Description Part No.
MAIN CBA (MCV-A)
Consists of the following:
----------
CAPACITORS
C002! METALIZED FILM CAP. 0.068µF/250V K or CT2E683DC011
! METALIZED FILM CAP. 0.068µF/250V K or CT2E683DC014
! METALIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C003! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C004 ELECTROLYTIC CAP. 33µF/400V M CE2HMZXJH330
C005 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C006 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C007 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C008 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C010 FILM CAP.(P) 0.022µF/100V J or CMA2AJP00223
FILM CAP (P) 0.022µF/50V J or CMA1JJP00223
FILM CAP.(P) 0.022µF/50V J or CA1J223MS029
POLYESTER FILM CAP. (PB FREE) 0.022µF/
100V J
CA2A223DT018
C011 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/16V H7 CE1CMAVSM100
C012 ELECTROLYTIC CAP. 10µF/50V M H7 or CE1JMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/50V H7 CE1JMAVSM100
C014 ELECTROLYTIC CAP. 470µF/35V M or CE1GMASDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMASTM471
C015 ELECTROLYTIC CAP. 47µF/25V M H7 or CE1EMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/25V H7 CE1EMAVSM470
C017 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C018 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101
C020 ELECTROLYTIC CAP. 1000µF/16V M or CE1CMASDL102
ALUMINUM ELECTROLYTIC CAP 1000µF/16V
M
CE1CMZPTM102
C021 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTM471
C022 ELECTROLYTIC CAP. 22µF/16V M H7 or CE1CMAVSL220
CAP ELE H7-85 22µF/16V H7 CE1CMAVSM220
C025 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C026 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/16V H7 CE1CMAVSM470
C053 ELECTROLYTIC CAP. 220µF/6.3V M H7 or CE0KMASSL221
ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSM221
C056 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C057 CHIP CERAMIC CAP.(1608) CH J 470pF/50V CHD1JJ3CH471
C151 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C152 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C154 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C155 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/16V H7 CE1CMAVSM100
C156 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/16V H7 CE1CMAVSM100
C157 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C158 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C159 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C251 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/16V H7 CE1CMAVSM100
C252 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C253 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C254 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C302 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C303 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C304 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C305 CHIP CERAMIC CAP. F Z 0.22µF/16V CHD1CZ30F224
C307 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C308 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C309 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C310 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C312 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C313 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C314 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C316 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C317 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/6.3V
H7
CE0KMAVSM470
C318 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C319 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/50V H7 CE1JMAVSM1R0
C320 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C321 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
Ref. No. Description Part No.
