MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY HG214BD 1VM220483B
A2 CASE TOP(ANTHRACITE) HE240ED 0VM101267
A3 CHASSIS HE470ED 0VM000174G
A7 BOTTOM PANEL HK47PED 1VM321769
A10! RATING LABEL HM212BD ----------
A20 ROHS SEAL E970RBD ----------
A42 SECURITY LABEL E8D81BD ----------
A43 CASE MARK LABEL HM212BD ----------
A44 TUC CODE LABEL HM212BD ----------
1B1 DECK ASSEMBLY CZD014/VM25A0 N25A0FL
2B5 SHEILD CYLINDER HG470ED 0VM306638
2B9 CUSHION HC460ED 0VM413251
2B18 FIBER TOP CASE HC460ED 0VM412906
2B36 LABEL EAS L0951UB ----------
2L011 SCREW P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L012 SCREW P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L021 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
2L031 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L041 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L042 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L051 SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
2L099 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 GIFT BOX CARTON HK214BD 1VM320988
S2 STYROFOAM(U27UK) HE471BD 0VM203890
S3 UNIT BAG V4010PA 0VM406453B
S9 AC PAD HC461BD 0VM413331
ACCESSORIES
X1 REMOTE CONTROL UNIT NA994ED NA994ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X20! OWNERS MANUAL HM212BD 1VMN22995
X36 QUICK SETUP GUIDE HM212BD 1VMN22996
