1-8-1 HM212FIS
FUNCTION INDICATOR SYMBOLS
Note:
The following symbols will appear on the indicator panel to indicate the current mode or operation of the VCR.
On-screen modes will also be momentarily displayed on the tv screen when you press the operation buttons.
Display panel
MODE INDICATOR ACTIVE
POWER ON " PWR." ON
CASSETTE "IN"
CASSETTE "OUT"
" "
" "
ON
OFF
CLOCK " 88:88 " ON
REC " REC " ON
REC PAUSE " REC " Blinks at 0.8Hz interval
T- R E C , OT R
" "
ON
(T-REC OFF,T-REC incomplete
Blinks at 0.8Hz interval)
RF OUT RF out channel number is displayed on the indicator panel.
S-INH condition All modes Blinks at 0.8Hz interval
All lighting mode All characters ON
