ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
RESISTORS DIODES
!R401 R4X5T6273FR,METAL 27K OHM 1/6W D802 D1VT001330DIODE,SILICON 1SS133T-77
!R408 R4X5T6103FR,METAL 10K OHM 1/6W D803 D1VT001330DIODE,SILICON 1SS133T-77
!R409 R4X5T6273FR,METAL 27K OHM 1/6W
ICS
!R429 R655812R7JR,FUSE 2.7 OHM 1W IC101 I56F07073A IC OEC7073A
R448 R3X18A821JR,METAL OXIDE 820 OHM 2W IC199 A3L101C015IC S-24C02BDP-1A
!R500 R0G3K2335KRC 3.3M OHM 1/2W !IC401 I01TD55220 IC AN5522
!R501 R5Y2CD5R6JR,CEMENT 5.6 OHM 5W IC601 I06FC61250 IC M61250FP
!R508 R3X181221JR,METAL OXIDE 220 OHM 1W IC1001 I01DP75110IC AN7511
!R509 R001T6221JRC 220 OHM 1/6W
TRANSISTORS
!R514 R63581R22JR,FUSE 0.22 OHM 1W !Q401 TD30026270TRANSISTOR SILICON 2SD2627LS-CBC11
!R515 R002T2124JRC 120K OHM 1/2W !Q402 TC5T01627YTRANSISTOR SILICON 2SC1627_Y(TPE2)
!R517 R3X1811R2JR,METAL OXIDE 1.2 OHM 1W !Q501 TJXG5NC500FET STP5NC50FP
!R518 R4X5T6562FR,METAL 5.6K OHM 1/6W !Q502 TCATC31980TRANSISTOR,SILICON KTC3198-AT(Y,GR)
!R519 R001T6122JRC 1.2K OHM 1/6W !Q504 0002E00610PHOTO COUPLER LTV-817M-VB
!R542 R3X181R68JR,METAL OXIDE 0.68 OHM 1W Q507 TCATC31980TRANSISTOR,SILICON KTC3198-AT(Y,GR)
!R629 R3X28B330JR,METAL OXIDE 33 OHM 3W Q603 TCAT032034TRANSISTOR, SILICON KTC3203_Y-AT
!R803 R3X181153JR,METAL OXIDE 15K OHM 1W Q604 TCAT032034TRANSISTOR, SILICON KTC3203_Y-AT
!R805 R3X181153JR,METAL OXIDE 15K OHM 1W Q605 TCAT032034TRANSISTOR, SILICON KTC3203_Y-AT
!R807 R3X181153JR,METAL OXIDE 15K OHM 1W Q606 TCAT032034TRANSISTOR, SILICON KTC3203_Y-AT
CAPACITORS
Q609 TCATC31980TRANSISTOR,SILICON KTC3198-AT(Y,GR)
C402 P3N1F2103JCPP 0.01 UF 200V Q610 TCATC31980TRANSISTOR,SILICON KTC3198-AT(Y,GR)
!C403 E02LT4471MCE 470 UF 35V !Q801 TCKT1473A0TRANSISTOR SILICON 2SC1473A-TA-(RQ)
!C414 E02LT4101MCE 100 UF 35V !Q802 TCKT1473A0TRANSISTOR SILICON 2SC1473A-TA-(RQ)
!C418 E02LT3471MCE 470 UF 25V !Q803 TCKT1473A0TRANSISTOR SILICON 2SC1473A-TA-(RQ)
!C434 E02LT8220MCE 22 UF 100V
COILS &TRANSFORMERS
C437 P4J7F3474JCMPP 0.47 UF 250V PMS L101 021LA63R3KCOIL 3.3 UH
!C443 P4N8FJ472HCMPP 0.0047UF 1.25KV L402 02186G180MCOIL 18 UH
C444 P4N8FJ471JCMPP 470 PF 1.25KV or !L501 029T00A7M1COIL,LINE FILTER 1R5A102F20
C0PLRR7Q2KCC 470 PF 2KV RR !L503 028R140030COIL,DEGAUSS 8R140030
!C446 E02LT5220MCE 22 UF 50V L601 021LA6R56MCOIL 0.56 UH
!C448 E5EZ0C220MCE 22 UF 200V L607 021LA6150KCOIL 15 UH
!C503 C0JTB0513KCC 0.001 UF 500V B L801 021673221KCOIL 220 UH
!C505 P2472B104MCMP 0.1 UF 275V PHE840 T401 045009003J TRANS,HORIZONTAL DRIVEETH09K14BZ
C506 CB3930MQ3MCC 0.0047UF 250V !T502 0481290904TRANSFORMER,SWITCHING81290904
C514 C0PLRR7U2KCC 680 PF 2KV RR
JACKS
!C515 E02LT2102MCE 1000 UF 16V J702 060Q401077RCA JACK AV1-09D-3
C517 C0PLRR7Q2KCC 470 PF 2KV RR J703 060Q401076RCA JACK AV1-09D-4
!C519 E02LT2471MCE 470 UF 16V !J801 066F120018SOCKET,CRT ISMS01S
C521 E5EZFB101MCE 100 UF 160V J1001 0602121012JACK,RCA 3.5 HSJ1403-01-010
!C526 E02LFC221MCE 220 UF 200V
SWITCHES
C634 CQG0CH412JCC 100 PF 50V CH SW101 0504201T31SWITCH,TACT SKHVBED010
C819 C0JBB0713KCC 0.001 UF 2KV B SW102 0504201T31SWITCH,TACT SKHVBED010
DIODES
SW103 0504201T31SWITCH,TACT SKHVBED010
D001 D97U03001BDIODE,ZENER MTZJ30B T-77 SW104 0504201T31SWITCH,TACT SKHVBED010
D403 D2WT011E10DIODE SILICON 11E1-EIC SW105 0504201T31SWITCH,TACT SKHVBED010
D404 D97U06R21BDIODE,ZENER MTZJ6.2B T-77
P.C.BOARD ASSEMBLIES
!D405 D2WTAU02A0DIODE SILICON AU02A-EIC PCB010 A3L122C010PCB ASS'Y TMA525A
D406 D1VT001330DIODE,SILICON 1SS133T-77 PCB110 A3L117C110PCB ASS'Y TCA384A
D407 D1VT001330DIODE,SILICON 1SS133T-77
MISCELLANEOUS
D408 D2WT011E10DIODE SILICON 11E1-EIC B503 024HT03553CORE,BEADS W5RH3.5X5X1.0
!D410 D2WTAU02A0DIODE SILICON AU02A-EIC !CD501 120R414903CORD AC BUSH 0R414903
!D411 D2WTAU02A0DIODE SILICON AU02A-EIC CF601 1029045R7GFILTER,SAW TSF5229P3
D501 D2WXN40050DIODE SILICON 1N4005-EIC CF603 1012T4R520FILTER,CERAMIC SFSRA4M50CF00-A0
!D502 D2WXN40050DIODE SILICON 1N4005-EIC CF604 1012T4R519FILTER,CERAMIC TRAP TPSRA4M50C00-A0
!D503 D2WXN40050DIODE SILICON 1N4005-EIC !CP401 069S450089CONNECTOR PCB SIDE A1561WV2-A5P
D504 D2WXN40050DIODE SILICON 1N4005-EIC !CP502 069S420110CONNECTOR PCB SIDE A1561WV2-2P
!D505 D2WXB290S0DIODE SILICON SB290S CP601 069E260659CONNECTOR PCB SIDE 00_8283_0611_00_000
D506 D97U01801BDIODE,ZENER MTZJ18B T-77 CP801 069W010030CONNECTOR PCB SIDE TBS-X01X-A1
D508 D1VT001330DIODE,SILICON 1SS133T-77 CD101A 06CH012002CORD CONNECTOR CH012002
!D509 D97U01801BDIODE,ZENER MTZJ18B T-77 CD101B 06CH012003CORD CONNECTOR CH012003
!D510 D2WXRU2AM0DIODE SILICON RU2AM-EIC CP802A 067N010039WIRE HOLDER 9253_010_000_000 or
D512 D1VT001330DIODE,SILICON 1SS133T-77 067U010049WIRE HOLDER B2013H02-10P
!D513 D2WXB290S0DIODE SILICON SB290S CP802B 067N010039WIRE HOLDER 9253_010_000_000 or
D514 D1VT001330DIODE,SILICON 1SS133T-77 067U010049WIRE HOLDER B2013H02-10P
D522 D1VT001330DIODE,SILICON 1SS133T-77 !F501 081PC04004FUSE 51MS040LCC
D528 D97U05R61BDIODE,ZENER MTZJ5.6B T-77 !FB401 043214029FTRANSFORMER FLYBACK 3214029F
D601 D1VT001330DIODE,SILICON 1SS133T-77 FH501 06710T0006HOLDER,FUSE EYF-52BC
D602 D97U08R21BDIODE,ZENER MTZJ8.2B T-77 FH502 06710T0006HOLDER,FUSE EYF-52BC
D604 D97U05R61BDIODE,ZENER MTZJ5.6B T-77 OS101 077Q037003REMOTE RECEIVER PIC-37143SY
D605 D2WT011E10DIODE SILICON 11E1-EIC S101 WHL6032014FLAT CABLE AWG26 10C BLACK 320MM
D606 D97U06R81BDIODE,ZENER MTZJ6.8B T-77 SP1001 070Y132018SPEAKER S08F21
D607 D97U05R61BDIODE,ZENER MTZJ5.6B T-77 !TH501 DF5EL3R0A0DEGAUSS ELEMENT ZPB45BL3R0A
D610 D97U01201BDIODE,ZENER MTZJ12B T-77 TM101 076N0DW010TRANSMITTER RC-DW010
D611 D97U01201BDIODE,ZENER MTZJ12B T-77 !TU001 0145K00056TUNER,VHF-UHF TECC1040PG32E
D612 D97U01201BDIODE,ZENER MTZJ12B T-77 !V801 098Y1404B9CRT W/DY A34JXV70X53N45
!D619 D97U05R11BDIODE,ZENER MTZJ5.1B T-77 X602 100CT3R505CRYSTAL HC-49/C
D801 D1VT001330DIODE,SILICON 1SS133T-77
J2-1
