16
2V 20µs/div 21 50V 20µs/div
200V 20µs/div
17
22 50V 20µs/div
SOUND/AV
0.5V 1ms/div
23
10V 5ms/div18
10V 5ms/div
19
1V 1ms/div24
50V 20µs/div
20
NOTE:The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
H-2
WAVEFORMS
200mV 500µs/div
25
26500mV 20µs/div
