GLOSTER GLADIATOR MK1
DURAFLY 1100MM PLUG AND FLY
5. The center of gravity (CG) for the Gladiator is approximately 88mm from the leading edge of the
upper wing. To obtain the correct CG, the 2200mAh 4S LiPo needs to go as far forward as possible.
Once in position, the battery should be retained using the foam block supplied in the kit.
DATUM
DATUM
DATUM
DATUM
No STEP No STEP
DATUM DATUMDATUM DATUM
C of G is 88mm from the
leading edge of the upper wing.
CG 88mm
CG LOCATION:
With assembly and set-up now complete,
your Durafly Mk1 Gloster Gladiator should now be ready for flight. However
we recommend you read and follow the advice given in the following pages
of this manual before flying.
18
