3
2.Insert vertical fin into horizontal stabilizer. Then carefully fit it to the fuselage. Then glue
as below show. Then using a pair of pliers(ball link pliers preferably )connect the elevator
push rod to the elevator control horn(A) and connect the Rudder push rod to the rudder
control horn(B).
1. Out of the box your Slowpoke comes with reinforced foam hinges. However before
assembly can begin, each hinge line must be flexed back and forth5-6 times to reduce
tension and load on the servo. Do this for all control surfaces before continuing.
KM 2x10mm
M 2mm
