PROPELLER REPLACEMENT
10
Weedless Propeller
Drive pin
Prop nut
Washer
PROPELLER REPLACEMENT
• Hold the propeller and loosen the prop nut with a pliers or a wrench.
• Remove prop nut and washer.
NOTE: If the drive pin is sheared/broken, you will need to hold the shaft steady with a
screwdriver blade pressed into the slot on the end of the shaft.
• Turn the old prop to horizontal (as illustrated) and pull it straight off. If the drive pin
falls out, push it back in.
• Align new propeller with drive pin.
• Install prop washer and prop nut.
• Tighten prop nut 1/4 turn past snub. (25-35 inch lbs.)
IMPORTANT:
If the prop nut is overtightened it may cause damage to the prop or
cause too much pressure/strain on the motor which may cause overheating or premature
battery drain.
CAUTION:
Disconnect the motor from the battery before beginning any prop work
or maintenance.
Slot End
