ADJUSTMENT
6
DEPTH ADJUSTMENT
• Firmly grasp the shaft and hold it steady.
• Loosen the steering tension knob and depth collar knob until the tube slides freely.
• Raise or lower the motor to the desired depth.
• Tighten depth collar knob to secure the motor in place.
STEERING ADJUSTMENT
Adjust the steering tension knob to provide enough tension to allow the motor to turn
freely, yet remain in position without being held or; Tighten the knob and lock the
motor in a preset position to leave your hands free for fishing.
IMPORTANT:
When setting the depth, be sure the top of the motor is
submerged at least 12” (30 cm) to avoid churning or agitation of surface water. The
propeller must be completely submerged.
Depth Collar Knob
Steering tension knob
