2
SPECIAL FEATURES
• A tiny built-in switching AC power supply is great for portability and cramped pit areas, yet can still deliver up to 7 amps
charge current!
• Fully adjustable charge currents and multi-chemistry adaptability for a wide range of applications.
• A custom cc/cv charge algorithm carefully charges lithium-polymer, lithium-ion, or lithium ferrite-phosphate (A123)
batteries fully and safely!
• A peak detection system with automatic trickle charge fi lls NiCd and NiMH packs completely, for optimum battery
voltage and run-time. 3-20mV adjustable peak detection helps to customize charger-to-battery performance.
• A custom reversed LCD with backlight – previously only available in expensive racing chargers – is great for easy
viewing in any condition. Shows input and output voltages, peak voltage, charge current, charge capacity and time,
and more!
• Push button controls and audible tones make for easy setup and control.
• A built-in fan helps to keep all electronics cool, for long-lasting performance.
• Built-in banana jacks allow for connection with many commonly found charge adapters. An adapter with standard plug
is included.
• A DC power lead with alligator clips easily connects to many 12V DC power sources.
• Solid-state reverse polarity and current overload safety devices ensure trouble-free operation and long duration.
IMPORTANT PRECAUTIONS
Disconnect the battery and remove input power from the charger immediately if the charger or battery
become hot!!
• Do not attempt to charge incompatible types of rechargeable batteries as permanent damage to the battery and charger
could result.
• Do not use automotive type battery chargers to power the charger.
• Do not allow water, moisture or foreign objects into the charger.
• Do not block the fan or air intake holes, which could cause the charger to overheat.
• Do not attempt to use batteries with more cells or total voltage than listed in the specifi cations.
• Do not overcharge batteries as permanent damage could result. Do not use a charge current rate which exceeds the safe
level of the battery.
• Do not leave the charger unattended while in use.
• Do not place the charger or battery on fl ammable surfaces or near combustible materials while in use, such as a carpet,
cluttered workbench, paper, plastic, vinyl, leather, and wood, inside an R/C model or full sized automobile!
• Do not connect the charger to AC and DC inputs at the same time.
• Allow the charger or battery to cool down between charges.
• Always disconnect the charger from the power source when not in use.
GLOSSARY OF TERMS
Amps (A): The unit of measure for charge current.
Milli-amps (mA): A unit of measure for current, being amps (A) multiplied by 1000 and listed as “mA”. So 2.5A is the
same as 2500mA (2.5 x 1000). Or, to convert mA to amps, divide the mA number by 1000. So 25mA is the same as
0.025A (25 divided by 1000).
Capacity and milli-amp hours (mAh): The amount of energy a battery can store is called its capacity, which is defi ned
as how much current a battery can supply constantly over one hour of time. Most hobby batteries are rated for capacity
in “mAh” or milli-amp hours. A 650mAh battery can deliver 650mA of current for one hour (650mA x 1hr = 650mAh).
A 3200mAh battery can deliver 3200mA (3.2A) of current for one hour (3200mA x 1hr = 3200mAh), etc.
“C” rating: Capacity is also referred to as the “C” rating. Some battery suppliers recommend charge currents based on
the battery’s “C” rating. A battery’s “1C” current is the same number as the battery’s rated capacity number, but noted
in mA or amps. A 600mAh battery has a 1C current value of 600mA, and a 3C current value of (3 x 600mA) 1800mA or
1.8A. The 1C current value for a 3200mAh battery would be 3200mA (3.2A), etc.
