XP702HP Parts List
30
# Part # Description Qty
1 808211-010 FRAME 1
2 91335 BOLT M6X35 4
3 804004 RUBBER DAMPING BRACKET 4
4 90023 LOCK NUT M6 4
5 90018 NUT M8 4
6 801025-001 WATER PUMP ASSY 1
6.1 7261 Pump body seat 1
6.2 94257 FLAT WASHER 4
6.3 91349 BOLT M8X40 4
6.4 7262 PACKING RING,WATER PUMP 1
6.5 7209 PACKING RING,WATER PUMP 1
6.6 246511 1
6.7 7263 FAN,RECOIL STARTER 1
6.8 7264 volute 1
6.9 7265 PACKING RING,WATER PUMP 1
6.10 7266 FAN,RECOIL STARTER 1
6.11 94214 FLAT WASHER Φ6XΦ10X1 1
6.12 91420 M8X55 1
6.13 7267 volute 1
6.14 7268 PACKING RING,WATER PUMP 1
6.15 7269 Pump body seat 1
6.16 7270 PACKING RING,WATER PUMP 1
6.17 91346 M8*25 6
6.18 7271 OUTLET 1
6.19 7272 PACKING RING,WATER PUMP 2
6.20 7273 plug?screw 2
6.21 7274 1
6.22 7275 INLET 1
6.23 7222 PACKING RING,WATER PUMP 2
6.24 7207 NUT 2
6.25 7208 SAM interface Pump 2
6.26 7223 CLIP 2
6.27 7225 FUEL FILTER 1
6.28 94214 BOLT M10X30 6
6.29 90075 NUT M10 6
6.30 94214 FLAT WASHER Φ10.3*Φ20.6*1.65 12
7 91348 BOLT M8X35 4
