DUROMAX XP7HP - Specifications

Displacement 208cc
Fuel Type ≥87 octane, ≤10% ethanol, unleaded gasoline
Dry Weight 32.6 lbs
Maximum Torque 13.2 N·m @ 2500 RPM
Compression Ratio 8.5:1
Bore X Stroke 70mm x 55mm
Engine Oil Capacity 20.3 . oz (0.6 L)
Fuel Tank Capacity 1 gal.
Lowest Idling Speed 1600 RPM ± 150 RPM
Dimensions LENGTH 14.6 in.
WIDTH 13 in.
HEIGHT 13.4 in.
Engine Type 4-Stroke OHV Forced-Air
Ignition System Non-Contact Transistor
Lubrication Mode Splash
Starting Type Recoil
Shaft Rotation Counter-Clockwise
Shaft Size 3/4” Diameter, 2-3/8” Long, 3/16” Keyway
Shaft End 5/16” size 24 UNF - Drilled and Tapped
Center of Shaft to Base 4.175”
Gasoline Consumption ≤395 g/kWh
