Product description
Technical data KV15
Typ A-038E
Electrical data
Type A-038E
Article no. 0839-73
Mains frequency Hz 50 60
Nominal voltage V 230 230
Rated output P1 (W) 200 220
Rated current A 1�3 1
Rotational speed min
-1
1440 1710
Duty cycle 100% 100%
Type of protection IP 54 54
General technical data
Suction capacity S
eff
l/min 38 38
End pressure P
abs
mbar 150 150
Sound pressure level dB(A) 54 56
Weight kg 6�4 6�4
Dimensions (l x w x h) mm 249 x 156 x 180 249 x 156 x 180
Dimensions (x; y) mm 80; 100 80; 100
Remarks
Ambient conditions for operation
Temperature °C +5 to +40 +5 to +40
EN
