Mounting
7.7 Circuit diagram
Compressor unit
CB
.
N
..
L
Z1
U2
U1/Z2
Figure 34: Single-phase AC motors
W1
V2
W2
U1 U2
V1
Figure 35: Three-phase AC motors, triangle connection
W1
W2
U2
U1V1
V2
Figure 36: Three-phase AC motors, star connection
EN
