Product description
Typ D-040E; B-061E
Electrical data
Type D-040E (12V) D-040E (24V) B-061E
Article no. 0839-25 0839-22 0575 1100
Mains frequency Hz - - 50 60
Nominal voltage V 12 VDC 24 VDC 3 ph� 400 3 ph� 400
Rated output P1 (W) 104 120 500 500
Rated current A 8�7 5 0�9 0�9
Rotational speed min
-1
1800 2000 2740 3200
Duty cycle 100% 100% 100% 100%
Type of protection IP 20 20 54 54
General technical data
Suction capacity S
eff
l/min 40 40 61 61
End pressure P
abs
mbar 150 150 150 150
Sound pressure level dB(A) 59 59 61 63
Weight kg 6 6 6�1 6�1
Dimensions (l x w x h)
mm
242 x 121 x
175
242 x 121 x
175
225 x 165 x
180
225 x 165 x
180
Dimensions (x; y) mm 155; 92/139 155; 92/139 80; 100 80; 100
Remarks
Ambient conditions for operation
Temperature °C +5 to +40 +5 to +40 +5 to +40 +5 to +40
