Durr Technik KK15 - Page 46

44 0678106030L02 1411V002
Product description
Type D-061E (24V)
Electrical data
Type D-061E (24V)
Article no. 0513 1100
Mains frequency Hz -
Nominal voltage V 24 VDC
Rated output P1 (W) 264
Rated current A 11
Rotational speed min
-1
2950
Duty cycle 100%
Type of protection IP 54
General technical data
Suction capacity S
eff
l/min 61
End pressure P
abs
mbar 150
Sound pressure level dB(A) 61
Weight kg 7�1
Dimensions (l x w x h) mm 234 x 137 x 190
Dimensions (x; y) mm 90; 112
Remarks
Ambient conditions for operation
Temperature °C +5 to +40
EN
