Dux 135ZN - Specifications; Tank Specifications; Dimensions

Owner’s Manual – Prodigy 4
6
H3071 3071 Rev. I
Specifications
System Components
Component Description
1 PTR Valve
2 Hot Water Outlet To House
3 Cold Water Inlet
Tank Specifications
Model Numbers 135ZN / 135ZL 170ZN / 170ZL
Capacity (L) 135 170
Net Weight Empty (kg) 72 86
Relief Valve Pressure (kPA) 1400 1400
Gas Consumption 135ZN: 23.5 MJ/h
135ZL: 22.5 MJ/h
170ZN: 27 MJ/h
170ZL: 26 MJ/h
* Temperature rise at 45°C and inlet temperature of 15°C using natural gas
Dimensions (mm)
A – Height 1601 1896
B – Hot Water Outlet 1327 1620
C – Cold Water Inlet 221 221
