Dux 135ZN - Gas Entry and Piping

Owner’s Manual – Prodigy 4
7
H3071 3071 Rev. I
Gas Connections
Refer to the Data Label for correct gas
type. Gas piping should be connected
through the side of the case (see gure
below).
The plastic grommet must be installed
around the pipe and clipped into the
case.
The gas control is tted with a RC½"/15
socket. A union connection should be
used.
Gas pipe sizes should be in accordance
with AS5601/AG601.
Gas entry
