Dux Proflo 80F1 User Manual

Owner’s Manual – Proflo Electric Storage Water Heaters
7
H0421 0421 Rev. J
Specifications
Tank Size
80L 125L 160L 250L 315L 315L
TWIN
ELEMENT
400L 400L
TWIN
ELEMENT
Storage Capacity (L) 90 128 164 259 324 324 416 416
Hot Water Delivery (L) 80 125 160 250 315 315 400 400
Twin Element Boost – – – – – 40 – 70
Net Weight Empty (kg) 40 48 59 88 103 103 114 114
Element(s) Sizes (kW) 1.8, 2.4,
3.6
1.8, 3.6 2.4, 3.6 3.6 3.6 2 × 3.6
or
2 × 4.8
3.6 2 × 3.6
Relief Valve:
Pressure (kPa) 1400 1400 1400 1000 1000 1000 1000 1000
Temperature (°C) 99
Power Rating (kW) 10kW
Nominal Dimensions
Tank Size 80L 125L 160L 250L 315L 400L
Total Height (A) 925 1062 1317 1444 1754 1703
Total Diameter (B) 490 532 532 617 617 705
Outlet Height (C) 750 857 1112 1231 1541 1466
Inlet Height (D) 175 206 206 215 215 240
Electrical Entry (E) 80 116 116 125 125 150
A
C
D
E
B
