INSTALLATION MANUAL
NEED HELP?
855-680-9595
STEP 1 | Unscrew the pin from the
shackle and remove the four isolators
from the pin. You may be able to do this
by hand, if not use your 3/8” tool.
STEP 2 | Identify what isolators will
be used by holding up the shackle and
tting the isolators between the outside
of your bumper mount and inside of the
shackle.
NOTE: Different variations of isolators will be
used based on the thickness of your bumper
D-Ring mount. In our case, our 1” thick D-Ring
mount accepted both 1/8” isolators.
Begin by unpacking all items and inspecting
for missing pieces or damage. If you have any
concerns, please contact the company the
product was purchased from. Extra hardware
may be included with the product.
(4) 1/8” Isolators
(4) 3/16” Isolators
(2) 7/16” Pin
HARDWARE INCLUDED
