Dwyer Instruments DH-006 User Manual

1
DIMENSIONS
1-3/4
[44.45]
4-1/2
[114.30]
1/2
[12.70]
4-1/2
[114.30]
3-19/32
[91.28]
1-15/16
[49.21]
3-25/32
[96.04]
Face Designed to Meet NEMA 4X (IP66)
PANEL CUT OUTS
Horizontal
3.620 in. + 0.032 - 0.0
(92.00 mm + 0.8 - 0.0)
1.772 in. + 0.024 - 0.0
(45.00 mm + 0.6 - 0.0)
