APPENDIX E
1. SPEED SENSOR ADJUSTMENT
If the monitor does not display speed or distance the speed sensor and
magnet may be misaligned. Follow these steps to check and realign.
Remove the motor cover
Check the spacing and alignment between the magnet on the right side of
the front roller and the speed sensor on the frame. The spacing must be
1/8”.
Loosened screw and slide speed sensor in or out of clamp.
Retighten screw
Replace the motor cover.
2. SERVICE QUESTIONS
!
