B GENERAL INFORMATION
1. CONSOLE
a) Contains 3 windows which are twenty rows “dots” (8high)
indicate each segment of a workout.
2. MAIN CONTROLLER
a) Contains power supply and control circuits
3. TREADMILL MOTOR
a) Variable speed reversing 0-90 volt DC motor.
b) Have three wires red, black and green.
c) If there is DC voltage on the Red wire (M+) the treadmill
motor will turn clockwise.
d) If there is DC voltage on the Black wire (M-) the treadmill
motor will turn counter-clockwise
e) The green wire is ground.
4. INCLINE MOTOR
a) Reversing 115 volts AC motor.
b) Have four wires, red, black, white and green.
c) Has one 3 pins cable of position sensor.
d) If there is AC voltage on the Red wire (DOWN) the incline
motor will increase the incline.
e) If there is AC voltage on the Black wire (UP) the incline motor
will decrease the incline.
f) The White wire (COM) is neutral.
